RELIABILITY: Engineered by Victron Energy to meet rigorous marine and automotive standards, featuring short-circuit protection and high-temperature derating for maximum safety.

Key Features

• ✔ Galvanic Isolation: 200V DC between input/output.
• ✔ Remote On-Off: No high-current switch required.
• ✔ Adjustable Output: Range between 10V and 15V.
• ✔ Parallel Ready: Connect unlimited units for more power.
• ✔ IP43 Protection: Splash-proof (terminals downward).

Technical Specs

Input Voltage Range:	20 - 35 V
Nominal Output:	12.2 V
Cont. Current (40°C):	30 A
Efficiency:	88%
Dimensions:	130 x 186 x 70 mm
Weight:	1.6 kg

Make/System	Model/Application	Notes
Marine Systems	24V House Battery Banks	Ideal for 12V navigation electronics.
RV / Motorhomes	24V Solar/Lithium Setups	Powers 12V lighting and pumps.
Commercial	Heavy Duty 24V Vehicles	Used for 12V auxiliary equipment.

Is this a genuine original part?

Yes, this is a genuine Victron Energy product, supplied in original packaging with a full manufacturer warranty.

Can I use this as a battery charger?

While this is a DC-DC converter, the output voltage is adjustable via a potentiometer, meaning it can be used to trickle charge or maintain a 12V battery. However, for intelligent 3-stage charging, we recommend the Orion-Tr "Smart" series.

What is the benefit of an 'Isolated' converter?

Isolated converters separate the input and output grounds. This eliminates ground loop interference and protects sensitive electronics from common-mode noise, making them the preferred choice for marine communications and audio systems.
