RELIABILITY: Hot-dip galvanized to provide a thick, protective zinc layer, offering superior resistance to saltwater corrosion and abrasion.

Key Features

• ✔ DIN 766 Standard: Precision calibrated for windlass gypsies.
• ✔ Short-Link Design: Optimal strength-to-weight ratio.
• ✔ Hot-Dip Galvanized: Maximum corrosion protection.
• ✔ Grade 30 (G30): Reliable high-tensile steel construction.

Technical Specs

Wire Diameter (A):	8mm (±0.3mm)
Pitch/Internal Length (L2):	24.0mm
External Width (B):	27.2mm
Breaking Load (BL):	2500 daN (~2549 kgf)
Total Length:	30 Metres
Weight (Approx):	42.0 kg (1.4kg/m)

Windlass Brand	Model/Application	Notes
Lewmar	Pro-Series, V-Series, CPX	Requires 8mm DIN766 Gypsy
Quick	Prince, Antares, Hector	Universal 8mm calibration
Lofrans	Project, Kobra, Tigres	Compatible with DIN766 specs
Maxwell	RC8, HRC Series	Verify gypsy pitch (24mm)

Is this a genuine original part?

Yes, this is a genuine Talamex brand product, a trusted European name in marine anchoring systems.

How do I know if it is compatible?

Check your windlass manual or the stamp on your windlass gypsy. If it specifies 8mm DIN 766, this chain is a guaranteed fit. If your windlass specifies 8mm ISO, the pitch may vary slightly; please verify before purchase.

Does this chain come with a certificate?

This chain is manufactured to Grade 30 standards and calibrated for windlass use. For lifting applications requiring Lloyd's or DNV certification, please contact us at 4boats.co.uk.
