RELIABILITY: Features a high-capacity macerator and self-priming scavenger pump with a permanent magnet motor and stainless steel shaft, engineered to withstand harsh marine environments.

Key Features

• ✔ Push-button electric flush operation
• ✔ Built-in macerator & scavenger pump
• ✔ High-grade white ceramic china bowl
• ✔ Baked enamel wood seat & lid
• ✔ Integrated backflow preventer

Technical Specs

Voltage:	24V DC
Max Current Draw:	10 Amps
Recommended Fuse:	15 Amps
Inlet Port:	3/4" (19mm)
Discharge Port:	1" (25mm) - 1.5" Adapter Incl.
Dimensions:	490 x 445 x 430 mm

Make/System	Model/Application	Notes
Jabsco	37010-Series (24V)	Direct interchange for pump & bowl pattern
Seaflo	SFMTE2-01 Series	Compact floor-mounted installations
Universal	Power & Sail Craft	Suitable for above/below waterline use

Is this a genuine original part?

This is a genuine Seaflo premium marine toilet. Seaflo is a leading global manufacturer of marine sanitation equipment, and this part is designed to meet or exceed original equipment (OE) standards.

How do I know if it is compatible?

Check the footprint and the voltage (24V). This unit is a direct replacement for Jabsco 37010-series 24V toilets. If you are replacing a manual toilet, ensure you have the required 24V DC power feed and 15A fuse protection.

What does "horizontally mounted" mean for this model?

This refers to the orientation of the motor and macerator pump assembly which sits horizontally at the base of the toilet. This standard configuration allows for a compact height, making it ideal for installation in tight head compartments on boats.
