Seaflo 750GPH 12V Bilge Pump [BP1G75001]
Non-Automatic 01-Series Marine Submersible Pump
The SEAFLO BP1G75001 is a high-performance, non-automatic submersible bilge pump designed for the demanding marine environment. As part of the 01-Series, it offers reliable water evacuation for small to medium-sized vessels. This pump is traditionally operated via a manual panel switch or an external float switch (sold separately).
Key Features
- ✔ Snap-lock strainer for easy cleaning
- ✔ Anti-Airlock and Ignition protection
- ✔ Fully submersible and moisture-tight
- ✔ Marine-grade blocked wiring
- ✔ Run-dry capable for normal workloads
Technical Specs
| Flow Rate: | 750 GPH (2839 LPH) |
| Voltage: | 12V DC |
| Amp Draw: | 2.5A |
| Fuse Size: | 5.0A |
| Outlet Dia: | 19mm (3/4") |
| Max Lift (Head): | 3.0m (10ft) |
| Wire Lead: | 18 AWG x 1m |
Compatibility / Fitment Guide
| System Type | Application | Mounting Notes |
|---|---|---|
| Marine Bilge | Fishing boats, yachts, and skiffs | Strainer fits industry standard footprints |
| Livewell System | Water circulation / aeration | Must be mounted below water line |
| 12V DC Power | Solar/Leisure battery systems | Intermittent duty cycle recommended |
OEM Cross Reference
| Manufacturer | Model Number / Series |
|---|---|
| Rule | 20R (800 GPH Series) |
| Attwood | Tsunami T800 (4608-7) |
| Johnson | Cartridge L550 / L650 |
Questions & Answers
Is this a genuine original part?
This is a premium quality aftermarket replacement part from Seaflo, manufactured to meet or exceed original equipment (OE) standards for marine reliability and safety.
How do I know if it is compatible?
Check the outlet diameter (3/4") and the footprint. Seaflo designed this series with industry-standard mounting tabs to allow for easy swaps from older Rule or Johnson pumps without redrilling holes.
Does this pump turn on automatically when it senses water?
No, this is a non-automatic model. It requires a manual switch or a separate float switch to turn it on and off. If you need a pump that senses water automatically, please see the Seaflo 11-Series or similar auto-models at 4Boats.
Note: Please verify your original part number and hose diameter (19mm) against the references above before purchasing. All technical data is sourced from Seaflo manufacturing specifications.
