SEAFLO 12V 800GPH BILGE PUMP (BP1G80013A)
13A Series Premium Non-Automatic Submersible Pump
The Seaflo BP1G80013A is a state-of-the-art non-automatic bilge pump designed for high-performance water evacuation in marine environments. Part of the innovative 13A Series, this pump features a unique split quick-connect joint design that allows the motor to be replaced or maintained in seconds without dismantling your plumbing. Built with a robust, high-efficiency motor and marine-grade materials, it offers superior reliability for sailboats and mid-sized motorboats.
Key Features
- ✔ Quick-Connect Design: Split lock nut allows for instant pump replacement.
- ✔ Integrated Check Valve: Prevents water from flowing back into the bilge.
- ✔ Submersible & Ignition Protected: Safe for use in petrol engine compartments.
- ✔ Industry Standard Strainer: Snap-off base fits common mounting patterns.
- ✔ Quiet Operation: Low vibration and high-efficiency motor.
Technical Specs
| Model: | BP1G80013A |
| Flow Rate: | 800 GPH / 3028 LPH |
| Voltage: | 12V DC |
| Amp Draw: | 3.5A |
| Max Head (Lift): | 3.0m (10ft) |
| Outlet Dia: | 29mm (1-1/8") |
| Wire Lead: | 1m (18 AWG) |
Compatibility / Fitment Guide
| Application | Model/Vessel Type | Notes |
|---|---|---|
| Marine Bilge | Boats up to 24 meters | Standard for mid-sized craft. |
| Standard Plumbing | 1-1/8" (29mm) Hose | Includes threaded straight fitting. |
| Float Switches | Seaflo SFS-20-01 | Compatible with most float switches. |
OEM Cross Reference
| Seaflo MPN | BP1G80013A, SFBP1-G800-13A |
| EAN/UPC | 6971170932030 |
| Replacement For | Standard 13 Series 800 GPH Bilge Pumps |
Questions & Answers
Is this a genuine Seaflo part?
Yes, this is a genuine Seaflo 13A Series bilge pump, supplied in original packaging with a 2-year manufacturer warranty.
How do I know if it is compatible?
Check the outlet size (29mm / 1-1/8") and the flow rate (800 GPH). This pump is a direct replacement for Seaflo 13 Series models and features an industry-standard base pattern.
Does this pump turn on automatically?
No, this is a non-automatic model. It must be connected to a dash-mounted panel switch or an external float switch (such as the Seaflo SFS-20-01) for operation.
Note: Please verify your plumbing diameter (1-1/8") and voltage requirements (12V) before purchasing. For expert assistance, visit 4boats.co.uk.
