SEAFLO 24V 600GPH Bilge Pump 13A Series BP2G60013A Submersible Marine Boat Water
SEAFLO 24V 600GPH Bilge Pump 13A Series BP2G60013A Submersible Marine Boat Water
Couldn't load pickup availability
SEAFLO BP2G60013A Bilge Pump
13A Series | 24V DC | 600 GPH Performance
The SEAFLO 13A Series BP2G60013A is a premium, non-automatic submersible bilge pump designed for the rigorous demands of marine environments. Engineered with a modular quick-connect joint, this pump allows for the motor to be removed or replaced in seconds without dismantling your plumbing or base—making it one of the most user-friendly pumps in the industry.
Key Features
- ✔ Quick-connect joint for rapid maintenance
- ✔ Entirely submersible & ignition protected
- ✔ Integrated check valve to prevent backflow
- ✔ Anti-airlock and moisture-tight sealing
- ✔ Stainless steel motor shaft
- ✔ Snap-lock strainer base fits industry standards
Technical Specs
| Model: | BP2G60013A |
| Voltage: | 24V DC |
| Flow Rate: | 600 GPH (2271 LPH) |
| Current Draw: | 1.5 Amps |
| Fuse Rating: | 3.0 Amps |
| Max Head: | 2.5m (7.5') |
| Outlet Dia: | 19mm (3/4") / 29mm (1 1/8") |
| Wire Lead: | 1m (18 AWG) |
Compatibility / Fitment Guide
| System Type | Application | Notes |
|---|---|---|
| Marine / Boat | Small craft up to 24m | Primary bilge water removal |
| RV / Industrial | Water transfer & Grey water | Requires 24V power supply |
| Solar Systems | Off-grid water management | Low amp draw for battery efficiency |
OEM Cross Reference
| SEAFLO Part Number | BP2G60013A, SFBP2-G600-13A |
| EAN | 6971170932023 |
| Standards Compliance | CE, RoHS, ISO 8846, ISO 8849 |
Questions & Answers
Is this a genuine SEAFLO part?
Yes, this is an authentic SEAFLO 13A Series bilge pump, sourced directly to ensure high performance and compliance with international marine standards.
Does this pump turn on automatically?
No, the 13A series is non-automatic. It must be operated via a manual panel switch or connected to a separate SEAFLO float switch for automatic operation.
Can I replace the motor without cutting my hoses?
Yes! The innovative split quick-connect joint allows the motor unit to be removed from the plumbing and strainer base in seconds, making maintenance or replacement effortless.
Note: Please verify your vessel's voltage (24V) before purchase. For 12V systems, please see our 12V SEAFLO range at 4boats.co.uk.
