RELIABILITY: Constructed with a corrosion-resistant housing and high-grade contacts, this switch is built to handle high-amperage marine pump loads while resisting the harsh saltwater environment.

Key Features

• ✔ Reversing Polarity: Enables dual-direction flow for pumps.
• ✔ 3-Position Control: Clear On-Off-On (Fill/Off/Drain) functionality.
• ✔ Mounting Bracket: Includes compact bracket for easy dash installation.
• ✔ Quick Connect: 6-pin terminal design for fast electrical setup.

Technical Specs

Model:	SP03008
Voltage:	12V / 24V DC
Amperage (12V):	Rated up to 25A
Terminals:	6-Pin
Material:	ABS / Marine Grade Metal

System/Make	Model Application	Notes
Seaflo Ballast Pumps	01 Series (G1100-01)	Direct replacement switch
Seaflo Ballast Pumps	02 Series High Flow	Compatible with reversing circuits
Wakeboard Ballast	Universal Reversible Systems	Common in Mastercraft, Moomba, Supra

Is this a genuine original part?

Yes, this is an authentic Seaflo manufactured part designed specifically for their line of marine ballast and water systems.

How do I know if it is compatible?

If you have a 2-wire reversible pump (like the Seaflo G1100) and require a 3-position switch (Fill-Off-Drain), this is the correct component. It uses a standard 6-pin configuration for cross-over polarity wiring.

Does this switch come with a wiring diagram?

The SP03008 follows standard DPDT reversing switch wiring. We recommend professional marine installation to ensure proper fuse protection and terminal crimping.
