VERSATILITY: Features a self-closing water valve that significantly reduces water flow into the hull when the paddlewheel insert is removed for cleaning or storage.

Key Features

• ✔ 3-in-1: Depth, Speed, & Temp
• ✔ Extended stem for thick hulls
• ✔ Dual Frequency (50/200 kHz)
• ✔ Robust Bronze construction
• ✔ Self-sealing removable insert

Technical Specs

Power Rating:	600W RMS
Frequency:	50 / 200 kHz
Beamwidth:	45° (50kHz) / 12° (200kHz)
Hole Diameter:	51mm (2")
Max Depth:	353m (1,200ft)
Housing:	Bronze (Long Stem)

System Type	Compatible Models	Notes
Raymarine Instruments	i40, i50, i70, ST40, ST60, ST60+	Analog Connection
Sonar Modules	CP300, CP370, DSM30, DSM300	Check connector type
Hull Materials	Fiberglass, Wood	Ideal for cored hulls

Is this a genuine original part?

This is a genuine Raymarine / Airmar manufactured part, designed specifically for Raymarine navigation and fishfinder systems.

How do I know if I need the "Long Stem" version?

The B744VL (Long Stem) provides approximately 2.5 inches (64mm) of additional length compared to the standard B744V. You need this version if you have a cored fiberglass hull, a wood hull, or if you are using a thick high-performance fairing block on a steep deadrise.

Does this include the High-Performance Fairing Block?

No, this SKU is for the transducer unit and mounting hardware only. If a fairing block is required for your installation, it must be purchased separately (Raymarine part number E66023).
