RELIABILITY: Built to meet strict marine standards with a waterproof face and a fully gimballed sensor capable of handling up to 30 degrees of pitch and roll.

Key Features

• ✔ Large, high-visibility digital display
• ✔ Red backlighting for night navigation
• ✔ 9 levels of adjustable electronic damping
• ✔ Auto-calibration to cancel magnetic errors
• ✔ Suitable for steel and aluminum hulls

Technical Specs

Voltage	12V DC (Nominal)
Current Draw	90mA (+10mA Light)
Resolution	1 Degree
Display Size	132 x 98 x 30 mm
Sensor Type	Remote Fluxgate
Cable Length	10 Meters

Vessel Type	System Type	Notes
Sailing Yachts	12V DC Marine	Standalone display with fluxgate sensor.
Motor Cruisers	12V DC Marine	Ideal for mounting on consoles with limited space.
Metal/Alloy Hulls	12V DC Marine	Sensor bypasses local hull magnetism.

Is this a genuine original part?

Yes, this is a genuine NASA Marine product, part of the established Target instrument range known for durability and accuracy.

How do I know if it is compatible?

We recommend checking the SKU/MPN and Cross Reference list provided above. This unit is a standard 12V marine instrument and will fit most cockpit panel mounts with a 78mm x 72mm cutout.

Can this compass be used on a steel or aluminum boat?

Yes. Because it uses a remote fluxgate sensor, you can mount the sensor in a location away from the metal hull structure (or on a mast/pulpit) to ensure an accurate reading, which is difficult with traditional magnetic compasses.
