RELIABILITY: Engineered and manufactured in the UK, the V2 system is designed for long-term durability with a proven masthead sensor and a low-power consumption 12V display.

Key Features

• ✔ 60 segment 360-degree direction display
• ✔ Selectable pointer styles (Single or Windex style)
• ✔ NMEA 0183 output (MWV sentence)
• ✔ Keypad adjustment for masthead alignment
• ✔ Multiple levels of red backlighting

Technical Specs

Voltage:	12V DC Nominal
Consumption:	50mA + 25mA illumination
Display Size:	110 x 110 mm
Panel Depth:	30 mm
Cable Length:	20 Metres
Anemometer:	210 x 140 mm

Category	Details
Included in Kit	Clipper Wind Display, V2 Masthead Sensor, 20m Cable, Weather Cover, Mounting Blocks.
Data Protocol	NMEA 0183 (MWV Sentence). Compatible with most modern chartplotters and NMEA repeaters.
Repeaters	Compatible with NASA Clipper Wind Repeater (sold separately).

Is this a genuine original part?

Yes, this is a genuine NASA Marine product, manufactured in Stevenage, England.

How do I know if it is compatible with my system?

This system uses NMEA 0183 (MWV sentence). It will interface with any plotter or instrument that accepts this standard marine data protocol. It is also a direct replacement for older Clipper Wind systems that use the same 110mm aperture.

What is the difference between the MK1 and V2 systems?

The V2 system features an upgraded masthead unit with enhanced hardware and signal processing, providing more stable readings and direct NMEA 0183 output from the masthead itself.
