Mooring Ring 166 AISI 316 - SWL 1,200 kg | 4Boats

Polished AISI 316 stainless steel mooring ring for secure deck mooring on yachts and workboats.

• Brand - Mooring Ring
• Model - 166
• Material - AISI 316 stainless steel (EN 10088 / ASTM A240), polished finish
• Safe working load (SWL) - 1,200 kg (2,646 lb)
• Breaking load - 6,000 kg (approx. 5:1 safety factor) (13,228 lb)
• Ring ID / OD - 60 mm / 110 mm (2.36 in / 4.33 in)
• Base plate size - 120 × 90 mm (4.72 × 3.54 in); hole pattern 90 × 60 mm centre-to-centre (3.54 × 2.36 in)
• Fixings - 4 × M10 through-bolts (not supplied)
• Care - rinse with fresh water after use; inspect fixings regularly; tighten to recommended torque; avoid abrasive cleaners
