Titan High Strength Shackle [10321196]
Premium 5/16" Forged Galvanised Marine Hardware
The Titan 10321196 is a high-tensile, hot-dipped galvanised bow shackle designed specifically for demanding marine environments. Unlike standard shackles, this high-strength version is forged from premium carbon steel to provide a significantly higher working load limit (WLL) relative to its size, making it the ideal choice for anchoring and mooring systems where safety and reliability are paramount.
Key Features
- ✔ High Strength: 30% stronger than standard Grade A shackles.
- ✔ Hot Dipped: Galvanised coating on both body and pin.
- ✔ Easy ID: Size and WLL stamped directly on the bail.
- ✔ Oversized Pin: 3/8" pin for a 5/16" shackle body.
- ✔ Black Pin: Distinctive black finish for easy visual identification.
Technical Specs
| Bail Size: | 5/16" (8mm) |
| Pin Diameter: | 3/8" (10mm) |
| Working Load (WLL): | 2,500 lbs (1,135 kg) |
| Breaking Strength: | 12,500 lbs |
| Material: | Forged Carbon Steel |
| Finish: | Hot Dipped Galvanised |
Compatibility / Fitment Guide
| Application | Recommended Use | Notes |
|---|---|---|
| Anchor Systems | Bow-to-Chain Connection | Fits 1/4" and 5/16" G4 chain sizes. |
| Mooring Gear | Buoy Connections | Suitable for long-term submersion. |
| Marine Rigging | Towing & Retrieval | Proof tested and load rated. |
OEM Cross Reference
| Brand / Distributor | Reference Number |
| Titan Marine | 10321196 |
| UPC / EAN | 628309211967 |
| Fisheries Supply | 449611 / ZNC 10321196 |
Questions & Answers
Is this a genuine original part?
This is a premium high-strength shackle manufactured by Titan Marine, a division of Canada Metal (Pacific), known for professional-grade marine hardware.
How do I know if it is compatible?
Measure the opening of your chain link or anchor shank. This shackle has a 5/16" body and a 3/8" pin. If your gear accommodates these dimensions, it is a guaranteed fit.
What makes the "High Strength" version different from a standard shackle?
Titan High Strength shackles use alloy steel and specific forging processes to achieve a 2,500lb WLL. A standard 5/16" shackle typically only offers around 1,500lb WLL.
Note: Please verify your required load limits and dimensions against the specifications above before purchasing. Distributed by 4boats.co.uk.
