Titan High Strength Shackle 10319619
1-3/8" Forged Galvanised Anchor Shackle - 42,000lb WLL
The Titan 10319619 is a heavy-duty, high-strength anchor shackle designed for professional marine and industrial applications where safety and durability are paramount. Forged from Grade 6 carbon steel, this shackle offers a 30% higher breaking strength than standard Grade A shackles, making it the ideal partner for High Test G4 or Grade 43/70 chain systems.
Key Features
- ✔ High Tensile Steel: Forged Grade 6 construction
- ✔ Oversized Black Pin: Easily identifies High Strength rating
- ✔ Corrosion Protection: Full Hot Dipped Galvanised finish
- ✔ Certified Safety: Proof-tested and load-rated for lifting/anchoring
Technical Specs
| Body Size: | 1-3/8" (35mm) |
| Pin Diameter: | 1-1/2" (38mm) |
| WLL: | 42,000 lbs (19,068 kg) |
| Breaking Load: | 210,000 lbs (95,340 kg) |
| Standard: | Exceeds RR-C-271 Type IV |
Compatibility / Fitment Guide
| Application | Model/Chain Compatibility | Notes |
|---|---|---|
| Anchor Rodes | High Test G4 / Grade 43 Chain | Exceeds chain strength |
| Mooring Systems | 1-1/4" to 1-3/8" Chain Diameters | Verify pin clearance |
| Heavy Rigging | Offshore / Commercial Lifting | Black pin Grade 6 identifier |
OEM Cross Reference
| Manufacturer | Part Number |
| Titan Marine (CMP Group) | 10319619 |
| UPC | 628309196196 |
| US Fed Spec | RR-C-271 Type IV Grade B |
Questions & Answers
Is this a genuine original part?
Yes, this is a genuine Titan Marine product, manufactured by CMP Group. Titan is a leader in marine mooring and anchoring equipment.
What does the black pin signify?
The bold black pin is Titan's signature identifier for their "High Strength" Grade 6 range, distinguishing it from standard Grade A shackles.
Can this be used for overhead lifting?
Titan shackles are proof-tested and load-rated, suitable for lifting and anchoring applications. Please ensure your specific lifting project complies with local safety regulations regarding SWL (Safe Working Load).
Note: Please verify your required bail size and pin diameter against the technical specifications above before purchasing. Distributed via 4boats.co.uk.
