Titan 1/2" High Strength Galv Bow Shackle 10319612 6600lb WLL Anchor Shackle
Titan 1/2" High Strength Galv Bow Shackle 10319612 6600lb WLL Anchor Shackle
Couldn't load pickup availability
Titan 1/2" High-Strength Bow Shackle 10319612
Hot Dipped Galvanised - 6,600 lbs WLL
The Titan 10319612 is a professional-grade High-Strength Bow Shackle engineered for demanding marine anchoring and rigging applications. Unlike standard Grade A shackles, this Grade B alloy shackle provides a significantly higher strength-to-weight ratio, making it the ideal partner for high-test G4 or G43 anchor chains.
Key Features
- ✔ 30% stronger than standard Grade A shackles
- ✔ Signature black screw pin for easy identification
- ✔ Hot-dipped galvanised on both body and pin
- ✔ Proof tested and load rated
- ✔ WLL and size stamped on every unit
Technical Specs
| SKU/MPN: | 10319612 |
| Bail Size: | 1/2" (13mm) |
| Pin Diameter: | 5/8" (16mm) |
| WLL: | 6,600 lbs (2,996 kg) |
| Breaking Strength: | Exceeds G4 Chain |
| Standard: | RR-C-271 Grade B |
Compatibility / Fitment Guide
| Application | Chain Size | Notes |
|---|---|---|
| Anchor Connections | 8mm to 10mm G43/G4 | Ideal for high-tensile anchor rodes. |
| Mooring Systems | Up to 1/2" Standard | Heavy-duty galvanised protection. |
| Marine Rigging | General Purpose | Forged alloy for safety-critical lifting. |
OEM Cross Reference
| Titan Marine ID | 10319612 |
| CMP Group Part | 10319612 |
| UPC Code | 628309196127 |
Questions & Answers
Is this a genuine original part?
This is a premium Titan Marine part by CMP Group, widely recognised as the industry standard for high-strength marine shackles.
How do I know if it is compatible?
Check your chain link size. This shackle uses a 5/8" pin and a 1/2" bail. If you are using G4/G43 chain, this shackle is specifically designed to match or exceed the chain's strength.
Why is the pin coloured black?
The bold black pin is Titan's signature indicator for their High-Strength (Grade B) alloy line, ensuring you can quickly identify it from standard strength (Grade A) shackles in your locker.
Note: Please verify your required Working Load Limit (WLL) against the specifications above before purchasing at 4boats.co.uk.
