Guest 4006 Standard Dynaplate Marine Grounding Plate Porous Bronze Bonding
Guest 4006 Standard Dynaplate Marine Grounding Plate Porous Bronze Bonding
Couldn't load pickup availability
Guest 4006 Standard Dynaplate
Premium Porous Bronze Grounding & Bonding Plate
The Guest 4006 Standard Dynaplate is the industry standard for marine grounding and lightning protection. Engineered from sintered porous bronze spheres, this plate provides thousands of tiny contact points with the water, creating a massive effective surface area in a compact, low-drag design. This specific model is highly recommended for boats requiring improved electronics performance and robust lightning dissipation without the need for long, cumbersome runs of copper foil.
Key Features
- ✔ Maximum Conductivity: Sintered porous bronze construction.
- ✔ Compact Power: Equivalent to 12 sq. ft. of copper foil.
- ✔ Corrosion Control: Deters electrolysis and galvanic corrosion.
- ✔ Easy Maintenance: Can be cleaned easily with a wire brush.
- ✔ Low Drag: Non-fouling, streamlined shape.
Technical Specs
| MPN | 4006 |
| Dimensions (In) | 6.0" L x 2.0" W x 0.5" D |
| Dimensions (mm) | 152 x 51 x 13 mm |
| Mounting Holes | 2-1/2" Center-to-center |
| Weight | 3.0 lbs (0.7 kg) |
| Copper Equiv. | 12 Square Feet |
Compatibility / Fitment Guide
| Application | Recommended Use | Notes |
|---|---|---|
| Lightning Protection | Primary Ground Path | Direct thru-hull installation required. |
| RF Grounding | SSB, Loran, Ham Radio | Reduces electrical noise/interference. |
| Bonding Systems | DC Electrical Bonding | Reduces hull damage risk from strikes. |
OEM Cross Reference
| Guest Part Number | 4006 / SUR 4006 |
| UPC Code | 046904400607 |
| ASAP Supplies Reference | 8-44006 |
Questions & Answers
Is this a genuine original part?
Yes, this is an authentic Guest (Marinco) Dynaplate, manufactured to meet strict marine safety and ABYC standards.
How do I know if it is compatible?
The 4006 Standard model is ideal for general bonding and lightning protection. If your vessel requires a higher surface area for SSB radio transmitters, you may consider the larger 4008 or 4012 models.
What hardware is included for installation?
The kit includes (1) 3" Gold plated bolt and nut, (1) 3" Bronze bolt and nut, and (3) Copper washers for a secure, high-conductivity connection.
Note: Please verify your grounding requirements against the technical specifications provided. For technical support, please contact 4boats.co.uk.
