AMC 25mm 170A Flexible Battery Cable Black 30m Reel Marine Automotive PVC25-30-B
AMC 25mm 170A Flexible Battery Cable Black 30m Reel Marine Automotive PVC25-30-B
Couldn't load pickup availability
AMC 25mm² Flexible Battery Cable - Black (30m Reel)
Professional Grade 170A Marine & Automotive Power Cable
The AMC PVC25-30-B is a high-specification, extra-flexible power cable designed for heavy-duty electrical systems. Manufactured in the UK by Auto Marine Cables, this 25mm² cable is engineered with a high strand count (322/0.30mm) to provide exceptional flexibility, making it easy to route through tight compartments in boats, motorhomes, and vehicles.
Key Features
- ✔ High-Flex Construction: 322 strands for easy installation
- ✔ Chemical Resistant: Protection against oils and acids
- ✔ UK Manufactured: Guaranteed quality and safety
- ✔ Bulk Reel: 30-meter length for large projects
Technical Specs
| Cross Section: | 25mm² (4 AWG) |
| Current Rating: | 170 Amps |
| Stranding: | 322 / 0.30mm |
| Overall Diameter: | 10.1 mm |
| Resistance: | 0.00077 Ω/m (@ 20°C) |
| Voltage Rating: | Max 60V DC |
| Temp Range: | -30°C to +70°C |
Compatibility / Fitment Guide
| System Type | Typical Application | Notes |
|---|---|---|
| Marine 12V/24V | Battery Banks, Inverters | Ideal for main battery interconnects |
| Marine Equipment | Bow Thrusters, Windlasses | Suits high-draw DC motors |
| Automotive | Starter Motors, Alternators | Heavy duty car/truck starter cable |
| Off-Grid Solar | Battery to Inverter wiring | Maximum continuous load 170A |
OEM Cross Reference
| AMC Part Number: | PVC25-30-B |
| ASAP Supplies Reference: | 8-00553-BK |
| Autotechnik SKU: | BCHF25-B-30 |
| 12 Volt Planet: | P00833 |
Questions & Answers
Is this a genuine original part?
This is a genuine Auto Marine Cables (AMC) product, manufactured in the UK to the highest industry standards for marine and automotive use.
How do I know if it is compatible?
Check the current requirements of your system. This cable is rated for 170 Amps continuous current. For high-load components like bow thrusters, please refer to the manufacturer's suggested cable gauge (typically 25mm² for medium-length runs).
Is the conductor tinned or plain copper?
The PVC25-30-B features plain copper conductors. If you require tinned copper for extreme saltwater environments, please look for the AMC "Oceanflex" range on our 4boats.co.uk store.
Note: Please verify your required amperage and voltage drop requirements against the cable specifications before purchasing.
