Actisense Micro NMEA 2000 Cable Per Metre - UL Certified A2K Bulk Lite Cable
Actisense Micro NMEA 2000 Cable Per Metre - UL Certified A2K Bulk Lite Cable
Couldn't load pickup availability
Actisense Micro NMEA 2000 Cable
UL Certified Bulk Lite Cable - Sold Per Metre
The Actisense A2K-BULK-C is a high-grade NMEA 2000 Micro Lite cable designed for building custom-length backbones or drop cables in marine electronics installations. This premium cable features five wires within a single waterproof jacket: dedicated power and ground wires, two signal (data) wires, and a drain wire. The integrated shield protects against Radio Frequency Interference (RFI), ensuring clean data transmission across your vessel's network.
Key Features
- ✔ Sold by the metre for custom lengths
- ✔ UL Certified for marine safety
- ✔ Tinned copper conductors for corrosion resistance
- ✔ Shielded pairs for RFI/EMI protection
- ✔ IP67 rated (when used with correct connectors)
Technical Specs
| Rated Voltage | 60V DC |
| Rated Current | 3 Amps |
| Power Pair | 22 AWG Tinned Copper |
| Data Pair | 24 AWG Tinned Copper |
| Outer Diameter | ~6.85mm |
| Temp Range | -20°C to +70°C |
Compatibility / Fitment Guide
| Make/System | Model/Application | Notes |
|---|---|---|
| NMEA 2000® | All Certified Devices | Universal standard compatibility |
| Garmin / Simrad / Lowrance | MFDs & Sensors | Uses standard Micro connectors |
| Raymarine | SeaTalkng Systems | Requires adapter for STng proprietary plugs |
| Actisense QNB-1 | Network Blocks | Ideal for barrier strip termination |
OEM Cross Reference
| Manufacturer | Part Number |
| Actisense | A2K-BULK-C (Per Metre) |
| Actisense Reel | A2K-BULK-100M |
| Standard Industry | DeviceNet Micro Cable |
Questions & Answers
Is this a genuine original part?
Yes, this is genuine Actisense A2K Micro Bulk cable, sourced directly to ensure the highest quality for your marine network.
How do I know if it is compatible?
This cable is NMEA 2000 certified. It is compatible with any device or connector designed for the NMEA 2000 / DeviceNet Micro standard.
What is the maximum length I can use for a backbone?
This Micro Lite cable can be used to create a backbone up to 100 metres in length. For drop cables (connecting devices to the backbone), the maximum recommended length is 6 metres per drop.
Note: Bulk cable is supplied per metre in a continuous length. Field-fit connectors (FFC) are required for termination (sold separately at 4boats.co.uk).
