RELIABILITY: Engineered by Victron Energy with high-frequency switching and a 5-year warranty for industrial-grade durability.

Key Features

• ✔ High Efficiency: Exceeds 95% at full load
• ✔ IP43 Protection: Splash-proof when installed correctly
• ✔ Screw Terminals: Simple installation without special tools
• ✔ Compact Design: Small footprint (53x51x27mm)
• ✔ Thermal Protection: Automatic derating at high temperatures

Technical Specs

Input Voltage Range	18-35V DC
Nominal Output	12.7V DC
Continuous Current	5 Amp
Max Output Power	60 Watts
Off-load Current	< 20mA
Operating Temp	-20 to +55°C
Weight	0.09 kg

Application	Model/Usage	Notes
Marine Systems	Boats with 24V house banks	Ideal for 12V GPS, VHF, and LED lighting
Heavy Vehicles	24V Trucks & Motorhomes	Powers 12V dashboard accessories
Off-Grid Solar	24V Solar Installations	Step down to 12V for small appliances

Is this a genuine original part?

Yes, this is a 100% genuine Victron Energy product, supplied in original packaging with a full 5-year manufacturer warranty.

Can I use this to charge a 12V battery from a 24V system?

This specific non-isolated model has a fixed 12.7V output and is intended as a power supply. For dedicated 3-stage battery charging, we recommend the Orion-Tr Smart DC-DC Charger range.

What does "non-isolated" mean?

Non-isolated means the input and output share a common negative ground. This is typical and safe for most boat and vehicle applications where a common ground is already in use.
