MerCruiser OMC Volvo Marine Starter Motor Offset Holes 3.0 4.3 5.0 5.7 M1786
MerCruiser OMC Volvo Marine Starter Motor Offset Holes 3.0 4.3 5.0 5.7 M1786
Couldn't load pickup availability
Marine Starter Motor M1786
Premium High-Torque PMGR Replacement
This M1786 marine starter motor is a high-performance, permanent magnet gear reduction (PMGR) unit designed for GM-based MerCruiser, OMC, and Volvo Penta engines. Engineered to provide superior cranking torque while drawing less current from your battery, it is an ideal upgrade or replacement for older, heavier direct-drive starters.
Key Features
- ✔ High-Torque PMGR: Better starts, less drain.
- ✔ Offset Mounting: Fits 14" (168-tooth) flywheels.
- ✔ Ignition Protected: Meets SAE J1171 standards.
- ✔ Direct Fit: Replaces Delco PG260M & older 10MT units.
Technical Specs
| Voltage: | 12V |
| Power Output: | 1.7 kW (~2.3 hp) |
| Rotation: | Clockwise (CW) |
| Teeth on Drive: | 11-Tooth |
| Mounting Pattern: | Offset / Staggered |
| Starter Type: | PMGR |
Compatibility / Fitment Guide
| Make/System | Model/Application | Notes |
|---|---|---|
| MerCruiser | 3.0L, 3.0LX, 4.3L V6, 5.0L & 5.7L V8 | Fits models 1990-Up |
| Volvo Penta | 3.0, 4.3, 5.0, 5.7 (GM Blocks) | PMGR Staggered Mount |
| OMC Cobra | 3.0L, 4.3L, 5.0L, 5.7L | Staggered Bolt Pattern |
| Caterpillar | Agricultural & Industrial (1998–2007) | GM-Pattern Industrial |
OEM Cross Reference
| MerCruiser / Mercury | 50-806964A2, 50-806964A3, 50-806964A4, 50-812428A2, 50-863030T1 |
| Volvo Penta | 3587625-10, 3854751, 3856004, 3860764, 3850526, 3855882 |
| OMC | 3854751, 3856004, 3850526, 3855882, 3856003 |
| Sierra / Arco | 18-5913 / 30124, 30460 |
| Other Refs | Delco 9000839, 9000840, 9000884; Lester 6791 |
Questions & Answers
Is this a genuine original part?
This is a premium quality aftermarket replacement part, manufactured to meet or exceed original equipment (OE) standards for fitment and performance.
How do I know if it is compatible?
We recommend checking the SKU/MPN and Cross Reference list provided above. If your original part number matches any of these, it is a guaranteed fit.
What is the difference between Offset and Inline holes?
Offset (or staggered) holes are designed for the larger 14-inch (168-tooth) flywheel commonly found on 3.0L, 4.3L, 5.0L, and 5.7L GM-based engines. If your current starter uses two bolts that are NOT aligned in a straight line, this M1786 unit is the correct replacement.
Note: Please verify your original part number against the references above before purchasing. Distributed by 4Boats / 4boats.co.uk.
